| Otomatik Doküman Besleyici |
Max.: 100 sheets |
|---|
| Geniş Kapasiteli Kağıt Besleme Ünitesi |
Paper feed unit PF-706
3 magazines; paper capacity: up to 6,000 sheets; paper weight: 40-350 gsm; standard paper sizes: A5 to A3+ (SRA3); min. paper size: 95 x 139 mm; max. paper size: 324 x 463 mm;
optional preprinted paper feed kit PP-701 available
Paper feed unit PF-703
3 magazines with air-suction technology; paper capacity: up to 5,000 sheets; paper weight: 40-350 gsm; standard paper sizes: A5 to A3+; min. paper size: 95 x 139 mm; max. paper size: 324 x 483 mm;
optional heating unit HT-505 available |
|---|
| Aktarım Ünitesi |
Relay unit RU-510
Sheet reverser |
|---|
| Kitapçık Ünitesi |
Saddle stitching kit SD-510 (for FS-532)
Booklet making of up to 20 sheets (80 images); saddle stitching; cover sheets from 50 to 300 gsm; output tray for booklets; multi-letter fold-in (up to 5 sheets); multi-half-fold
(up to 5 sheets) |
|---|
| Delme Ünitesi |
Punch kit PK-505 (for FS-532)
Punching (2 and 4 holes selectable) |
|---|
| Kapak/Sayfa Ekleme Ünitesi |
Post insertion unit PI-502 (for FS-532)
Insertion of preprinted sheets; PI trays for 200 sheets each |
|---|
| Katlama ve Delme Ünitesi |
Folding and punching unit FD-503
Preprinted sheet insertion (PI): 2 PI trays for 500 sheets each punching (2 and 4 hole); folding (half-fold, Z-fold, gate-fold, letter fold-in, letter fold-out, double-parallel-fold); sub tray for up to 200 sheets |
|---|
| Zımbalama Ünitesi |
Stapling unit FS-532
Stapling of up to 100 sheets; two-point and corner stapling; variable staple length (cutting mechanism); output for up to 4,200 sheets (A4); sub tray for up to 200 sheets; auto-shift sorting and grouping |
|---|
| Kitapçık Ünitesi |
Booklet making unit SD-506
Booklet making of up to 50 sheets (200 images); saddle stitching, trimming; output tray for up to 50 booklets; sub tray for up to 200 sheets; Multi-letter fold-in (up to 5 sheets); multi-half-fold (up to 5 sheets) |
|---|
| İstifleyici |
Stacking unit LS-505
Up to 5,000 sheets stacking capacity; up to three units can be installed; up to 15,000 sheets stacking capacity; trolley mounted stacker; auto-shift stacking;
sub tray for up to 200 sheets; paper clamp mechanism |
|---|
| Isısal Ciltleme Ünitesi (Perfect Binding) |
Perfect binding unit PB-503
Hot melt glue binding system; integrated 1-side trimming of cover sheets; books from A5 up to A4+ (307 x 221 mm); books from 10 sheets up to 30 mm spine width; cover paper tray for up to 1,000 sheets; sub tray for up to 200 sheets; book stacking capacity; 3,300 sheets; (2 stacks) |
|---|
| Spiral Delme (GBC) Ünitesi |
Multi (GBC) punching unit GP-501
Multi punching of A4 sheets; user replaceable die sets for: velo bind, plastic comb, wire bind, colour coil, pro click; paper weight: 75-216 gsm |
|---|
| Kağıt Nemlendirme Ünitesi |
Humidifier unit HM-101
Humidification decurler |
|---|
